| Product code | Luminous flux (lm) | Correlated color temperature (K) | Color rendering index (CRI) | Unified glare rating (UGR) | Wired lighting control | IP Code | Luminaire shape | Length (mm) | | Info | Add |
|---|
| EV-SARN/1X4/ST/GR/840SARN/1X4/ST/GR/840 | 2400 | 4000 | N/A | N/A | N/A | IP 65 | N/A | | - | EV-SARN/1X4/ST/GR/840SARN/1X4/ST/GR/840ArrowEV-SARN/1X4/ST/GR/840SARN/1X4/ST/GR/840Luminaire type: Industrial
Mounting type: surafce or suspended
Mounting location: ceiling
Luminous flux (lm): 2400
Correlated color temperature (K): 4000
Color rendering index (CRI): N/A
Median useful life: 50,000(h)
Standard Deviation of Color Matching (SDCM): N/A
Photobiological risk group: N/A
Luminous intensity distribution direction: N/A
Beam angle: 120
Luminous intensity distribution: N/A
Colour: N/A
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Voltage (V AC): 220-240
Power (W): 17.82
Wired lighting control: N/A
IP Code: IP 65
IK Code: IK08
Diffuser material: polycarbonate
Diffuser type: opal
Reflector material: N/A
Reflector Surface: N/A
Housing material: ABS
Luminaire shape: N/A
Permissible ambient temperature range: N/A
Circuit load capacity (B10): N/A
Circuit load capacity (B16): N/A
Weight (kg): N/A
| |
| EV-SARN/1X4/M3/GR/840 | 2400 | 4000 | N/A | N/A | N/A | IP 65 | N/A | | - | EV-SARN/1X4/M3/GR/840ArrowEV-SARN/1X4/M3/GR/840Luminaire type: Industrial
Mounting type: surafce or suspended
Mounting location: ceiling
Luminous flux (lm): 2400
Correlated color temperature (K): 4000
Color rendering index (CRI): N/A
Median useful life: 50,000(h)
Standard Deviation of Color Matching (SDCM): N/A
Photobiological risk group: N/A
Luminous intensity distribution direction: N/A
Beam angle: 120
Luminous intensity distribution: N/A
Colour: N/A
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Voltage (V AC): 220-240
Power (W): 18.16
Wired lighting control: N/A
IP Code: IP 65
IK Code: IK08
Diffuser material: polycarbonate
Diffuser type: opal
Reflector material: N/A
Reflector Surface: N/A
Housing material: polycarbonate
Luminaire shape: N/A
Permissible ambient temperature range: N/A
Circuit load capacity (B10): N/A
Circuit load capacity (B16): N/A
Weight (kg): N/A
| |
| EV-SARN/2X4/ST/GR/840 | 4750 | 4000 | N/A | N/A | N/A | IP 65 | N/A | | - | EV-SARN/2X4/ST/GR/840ArrowEV-SARN/2X4/ST/GR/840Luminaire type: Industrial
Mounting type: surafce or suspended
Mounting location: ceiling
Luminous flux (lm): 4750
Correlated color temperature (K): 4000
Color rendering index (CRI): N/A
Median useful life: 50,000(h)
Standard Deviation of Color Matching (SDCM): N/A
Photobiological risk group: N/A
Luminous intensity distribution direction: N/A
Beam angle: 120
Luminous intensity distribution: N/A
Colour: N/A
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Voltage (V AC): 220-240
Power (W): 36.8
Wired lighting control: N/A
IP Code: IP 65
IK Code: IK08
Diffuser material: polycarbonate
Diffuser type: opal
Reflector material: N/A
Reflector Surface: N/A
Housing material: ABS
Luminaire shape: N/A
Permissible ambient temperature range: N/A
Circuit load capacity (B10): N/A
Circuit load capacity (B16): N/A
Weight (kg): N/A
| |
| EV-SARN/2X4/M3/GR/840 | 4750 | 4000 | N/A | N/A | N/A | IP 65 | N/A | | - | EV-SARN/2X4/M3/GR/840ArrowEV-SARN/2X4/M3/GR/840Luminaire type: Industrial
Mounting type: surafce or suspended
Mounting location: ceiling
Luminous flux (lm): 4750
Correlated color temperature (K): 4000
Color rendering index (CRI): N/A
Median useful life: 50,000(h)
Standard Deviation of Color Matching (SDCM): N/A
Photobiological risk group: N/A
Luminous intensity distribution direction: N/A
Beam angle: 120
Luminous intensity distribution: N/A
Colour: N/A
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Voltage (V AC): 220-240
Power (W): 38.8
Wired lighting control: N/A
IP Code: IP 65
IK Code: IK08
Diffuser material: polycarbonate
Diffuser type: opal
Reflector material: N/A
Reflector Surface: N/A
Housing material: polycarbonate
Luminaire shape: N/A
Permissible ambient temperature range: N/A
Circuit load capacity (B10): N/A
Circuit load capacity (B16): N/A
Weight (kg): N/A
| |
| EV-SARN/1X5/ST/GR/840 | 3800 | 4000 | N/A | N/A | N/A | IP 65 | N/A | | - | EV-SARN/1X5/ST/GR/840ArrowEV-SARN/1X5/ST/GR/840Luminaire type: Industrial
Mounting type: surafce or suspended
Mounting location: ceiling
Luminous flux (lm): 3800
Correlated color temperature (K): 4000
Color rendering index (CRI): N/A
Median useful life: 50,000(h)
Standard Deviation of Color Matching (SDCM): N/A
Photobiological risk group: N/A
Luminous intensity distribution direction: N/A
Beam angle: 120
Luminous intensity distribution: N/A
Colour: N/A
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Voltage (V AC): 220-240
Power (W): 30.5
Wired lighting control: N/A
IP Code: IP 65
IK Code: IK08
Diffuser material: polycarbonate
Diffuser type: opal
Reflector material: N/A
Reflector Surface: N/A
Housing material: ABS
Luminaire shape: N/A
Permissible ambient temperature range: N/A
Circuit load capacity (B10): N/A
Circuit load capacity (B16): N/A
Weight (kg): N/A
| |
| EV-SARN/1X5/M3/GR/840 | 3800 | 4000 | N/A | N/A | N/A | IP 65 | N/A | | - | EV-SARN/1X5/M3/GR/840ArrowEV-SARN/1X5/M3/GR/840Luminaire type: Industrial
Mounting type: surafce or suspended
Mounting location: ceiling
Luminous flux (lm): 3800
Correlated color temperature (K): 4000
Color rendering index (CRI): N/A
Median useful life: 50,000(h)
Standard Deviation of Color Matching (SDCM): N/A
Photobiological risk group: N/A
Luminous intensity distribution direction: N/A
Beam angle: 120
Luminous intensity distribution: N/A
Colour: N/A
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Voltage (V AC): 220-240
Power (W): 30.5
Wired lighting control: N/A
IP Code: IP 65
IK Code: IK08
Diffuser material: polycarbonate
Diffuser type: opal
Reflector material: N/A
Reflector Surface: N/A
Housing material: polycarbonate
Luminaire shape: N/A
Permissible ambient temperature range: N/A
Circuit load capacity (B10): N/A
Circuit load capacity (B16): N/A
Weight (kg): N/A
| |
| EV-SARN/2X5/ST/GR/840 | 3800 | 4000 | N/A | N/A | N/A | IP 65 | N/A | | - | EV-SARN/2X5/ST/GR/840ArrowEV-SARN/2X5/ST/GR/840Luminaire type: Industrial
Mounting type: surafce or suspended
Mounting location: ceiling
Luminous flux (lm): 3800
Correlated color temperature (K): 4000
Color rendering index (CRI): N/A
Median useful life: 50,000(h)
Standard Deviation of Color Matching (SDCM): N/A
Photobiological risk group: N/A
Luminous intensity distribution direction: N/A
Beam angle: 120
Luminous intensity distribution: N/A
Colour: N/A
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Voltage (V AC): 220-240
Power (W): 51.8
Wired lighting control: N/A
IP Code: IP 65
IK Code: IK08
Diffuser material: polycarbonate
Diffuser type: opal
Reflector material: N/A
Reflector Surface: N/A
Housing material: ABS
Luminaire shape: N/A
Permissible ambient temperature range: N/A
Circuit load capacity (B10): N/A
Circuit load capacity (B16): N/A
Weight (kg): N/A
| |
| EV-SARN/2X5/M3/GR/840 | 3800 | 4000 | N/A | N/A | N/A | IP 65 | N/A | | - | EV-SARN/2X5/M3/GR/840ArrowEV-SARN/2X5/M3/GR/840Luminaire type: Industrial
Mounting type: surafce or suspended
Mounting location: ceiling
Luminous flux (lm): 3800
Correlated color temperature (K): 4000
Color rendering index (CRI): N/A
Median useful life: 50,000(h)
Standard Deviation of Color Matching (SDCM): N/A
Photobiological risk group: N/A
Luminous intensity distribution direction: N/A
Beam angle: 120
Luminous intensity distribution: N/A
Colour: N/A
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Voltage (V AC): 220-240
Power (W): 51.8
Wired lighting control: N/A
IP Code: IP 65
IK Code: IK08
Diffuser material: polycarbonate
Diffuser type: opal
Reflector material: N/A
Reflector Surface: N/A
Housing material: polycarbonate
Luminaire shape: N/A
Permissible ambient temperature range: N/A
Circuit load capacity (B10): N/A
Circuit load capacity (B16): N/A
Weight (kg): N/A
| |
