| Product code | Luminous flux (lm) | Correlated color temperature (K) | Color rendering index (CRI) | Unified glare rating (UGR) | Wired lighting control | IP Code | Luminaire shape | Length (mm) | | Info | Add |
|---|
| EV-K11TK2040OP9TWDRW | 2000 | Tunable white | >90 | N/A | DALI | IP 43 | cylindrical | N/A | - | EV-K11TK2040OP9TWDRWKombic 100 Surface Track Opal TWEV-K11TK2040OP9TWDRWDownlight with luminous flux of 2000lm. A wide range of technical parameters and appearance of the luminaire will ensure adaptation to various applications. a faceted range of polycarbonate reflector options guarantee optimal construction of the optical system and high efficiency. I protection class guarantees a high level of safety. Available with CRI 90. Luminaire type: track and spot
Mounting type: surface mounting
Mounting location: ceiling
Luminous flux (lm): 2000
Maximum luminous efficacy (lm/W): N/A
Correlated color temperature (K): Tunable white
Color rendering index (CRI): >90
Median useful life: Lifetime: 70.000 L80 B10
Standard Deviation of Color Matching (SDCM): N/A
Luminous intensity distribution direction: N/A
Beam angle: N/A
Luminous intensity distribution: N/A
Colour: white 02
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Angle 65° luminance: N/A
Voltage (V AC): 230
Power (W): 20,7
Wired lighting control: DALI
Wireless lighting control: N/A
IP Code: IP 43
IK Code: N/A
IEC protection class: I
Diffuser material: N/A
Reflector material: polycarbonate
Reflector Finish: bright
Housing material: aluminium
Luminaire shape: cylindrical
Permissible ambient temperature range: from 0u00c2u00b0C to 25u00c2u00b0C
Width (mm): N/A
Length (mm): N/A
Height (mm): 220
Weight (kg): N/A
Diameter (mm): 100
Adjustable: yes
Optics: opal
Installation: track
| |
| EV-K11TK2040OP9TWDRB | 2000 | Tunable white | >90 | N/A | DALI | IP 43 | cylindrical | N/A | - | EV-K11TK2040OP9TWDRBKombic 100 Surface Track Opal TWEV-K11TK2040OP9TWDRBDownlight with luminous flux of 2000lm. A wide range of technical parameters and appearance of the luminaire will ensure adaptation to various applications. a faceted range of polycarbonate reflector options guarantee optimal construction of the optical system and high efficiency. I protection class guarantees a high level of safety. Available with CRI 90. Luminaire type: track and spot
Mounting type: surface mounting
Mounting location: ceiling
Luminous flux (lm): 2000
Maximum luminous efficacy (lm/W): N/A
Correlated color temperature (K): Tunable white
Color rendering index (CRI): >90
Median useful life: Lifetime: 70.000 L80 B10
Standard Deviation of Color Matching (SDCM): N/A
Luminous intensity distribution direction: N/A
Beam angle: N/A
Luminous intensity distribution: N/A
Colour: black 02
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Angle 65° luminance: N/A
Voltage (V AC): 230
Power (W): 20,7
Wired lighting control: DALI
Wireless lighting control: N/A
IP Code: IP 43
IK Code: N/A
IEC protection class: I
Diffuser material: N/A
Reflector material: polycarbonate
Reflector Finish: bright
Housing material: aluminium
Luminaire shape: cylindrical
Permissible ambient temperature range: from 0u00c2u00b0C to 25u00c2u00b0C
Width (mm): N/A
Length (mm): N/A
Height (mm): 220
Weight (kg): N/A
Diameter (mm): 100
Adjustable: yes
Optics: opal
Installation: track
| |
| EV-K11TK2040OP9TWDMW | 2000 | Tunable white | >90 | N/A | DALI | IP 43 | cylindrical | N/A | - | EV-K11TK2040OP9TWDMWKombic 100 Surface Track Opal TWEV-K11TK2040OP9TWDMWDownlight with luminous flux of 2000lm. A wide range of technical parameters and appearance of the luminaire will ensure adaptation to various applications. a faceted range of polycarbonate reflector options guarantee optimal construction of the optical system and high efficiency. I protection class guarantees a high level of safety. Available with CRI 90. Luminaire type: track and spot
Mounting type: surface mounting
Mounting location: ceiling
Luminous flux (lm): 2000
Maximum luminous efficacy (lm/W): N/A
Correlated color temperature (K): Tunable white
Color rendering index (CRI): >90
Median useful life: Lifetime: 70.000 L80 B10
Standard Deviation of Color Matching (SDCM): N/A
Luminous intensity distribution direction: N/A
Beam angle: N/A
Luminous intensity distribution: N/A
Colour: white 02
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Angle 65° luminance: N/A
Voltage (V AC): 230
Power (W): 20,7
Wired lighting control: DALI
Wireless lighting control: N/A
IP Code: IP 43
IK Code: N/A
IEC protection class: I
Diffuser material: N/A
Reflector material: polycarbonate
Reflector Finish: metalized metalic
Housing material: aluminium
Luminaire shape: cylindrical
Permissible ambient temperature range: from 0u00c2u00b0C to 25u00c2u00b0C
Width (mm): N/A
Length (mm): N/A
Height (mm): 220
Weight (kg): N/A
Diameter (mm): 100
Adjustable: yes
Optics: opal
Installation: track
| |
| EV-K11TK2040OP9TWDMB | 2000 | Tunable white | >90 | N/A | DALI | IP 43 | cylindrical | N/A | - | EV-K11TK2040OP9TWDMBKombic 100 Surface Track Opal TWEV-K11TK2040OP9TWDMBDownlight with luminous flux of 2000lm. A wide range of technical parameters and appearance of the luminaire will ensure adaptation to various applications. a faceted range of polycarbonate reflector options guarantee optimal construction of the optical system and high efficiency. I protection class guarantees a high level of safety. Available with CRI 90. Luminaire type: track and spot
Mounting type: surface mounting
Mounting location: ceiling
Luminous flux (lm): 2000
Maximum luminous efficacy (lm/W): N/A
Correlated color temperature (K): Tunable white
Color rendering index (CRI): >90
Median useful life: Lifetime: 70.000 L80 B10
Standard Deviation of Color Matching (SDCM): N/A
Luminous intensity distribution direction: N/A
Beam angle: N/A
Luminous intensity distribution: N/A
Colour: black 02
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Angle 65° luminance: N/A
Voltage (V AC): 230
Power (W): 20,7
Wired lighting control: DALI
Wireless lighting control: N/A
IP Code: IP 43
IK Code: N/A
IEC protection class: I
Diffuser material: N/A
Reflector material: polycarbonate
Reflector Finish: metalized metalic
Housing material: aluminium
Luminaire shape: cylindrical
Permissible ambient temperature range: from 0u00c2u00b0C to 25u00c2u00b0C
Width (mm): N/A
Length (mm): N/A
Height (mm): 220
Weight (kg): N/A
Diameter (mm): 100
Adjustable: yes
Optics: opal
Installation: track
| |
| EV-K11ST2040OP9TWDRW | 2000 | Tunable white | >90 | N/A | DALI | IP 43 | cylindrical | N/A | - | EV-K11ST2040OP9TWDRWKombic 100 Surface Track Opal TWEV-K11ST2040OP9TWDRWDownlight with luminous flux of 2000lm. A wide range of technical parameters and appearance of the luminaire will ensure adaptation to various applications. a faceted range of polycarbonate reflector options guarantee optimal construction of the optical system and high efficiency. I protection class guarantees a high level of safety. Available with CRI 90. Luminaire type: track and spot
Mounting type: surface mounting
Mounting location: ceiling
Luminous flux (lm): 2000
Maximum luminous efficacy (lm/W): N/A
Correlated color temperature (K): Tunable white
Color rendering index (CRI): >90
Median useful life: Lifetime: 70.000 L80 B10
Standard Deviation of Color Matching (SDCM): N/A
Luminous intensity distribution direction: N/A
Beam angle: N/A
Luminous intensity distribution: N/A
Colour: white 02
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Angle 65° luminance: N/A
Voltage (V AC): 230
Power (W): 20,7
Wired lighting control: DALI
Wireless lighting control: N/A
IP Code: IP 43
IK Code: N/A
IEC protection class: I
Diffuser material: N/A
Reflector material: polycarbonate
Reflector Finish: bright
Housing material: aluminium
Luminaire shape: cylindrical
Permissible ambient temperature range: from 0u00c2u00b0C to 25u00c2u00b0C
Width (mm): N/A
Length (mm): N/A
Height (mm): 220
Weight (kg): N/A
Diameter (mm): 100
Adjustable: yes
Optics: opal
Installation: sus. track
| |
| EV-K11ST2040OP9TWDRB | 2000 | Tunable white | >90 | N/A | DALI | IP 43 | cylindrical | N/A | - | EV-K11ST2040OP9TWDRBKombic 100 Surface Track Opal TWEV-K11ST2040OP9TWDRBDownlight with luminous flux of 2000lm. A wide range of technical parameters and appearance of the luminaire will ensure adaptation to various applications. a faceted range of polycarbonate reflector options guarantee optimal construction of the optical system and high efficiency. I protection class guarantees a high level of safety. Available with CRI 90. Luminaire type: track and spot
Mounting type: surface mounting
Mounting location: ceiling
Luminous flux (lm): 2000
Maximum luminous efficacy (lm/W): N/A
Correlated color temperature (K): Tunable white
Color rendering index (CRI): >90
Median useful life: Lifetime: 70.000 L80 B10
Standard Deviation of Color Matching (SDCM): N/A
Luminous intensity distribution direction: N/A
Beam angle: N/A
Luminous intensity distribution: N/A
Colour: black 02
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Angle 65° luminance: N/A
Voltage (V AC): 230
Power (W): 20,7
Wired lighting control: DALI
Wireless lighting control: N/A
IP Code: IP 43
IK Code: N/A
IEC protection class: I
Diffuser material: N/A
Reflector material: polycarbonate
Reflector Finish: bright
Housing material: aluminium
Luminaire shape: cylindrical
Permissible ambient temperature range: from 0u00c2u00b0C to 25u00c2u00b0C
Width (mm): N/A
Length (mm): N/A
Height (mm): 220
Weight (kg): N/A
Diameter (mm): 100
Adjustable: yes
Optics: opal
Installation: sus. track
| |
| EV-K11ST2040OP9TWDMW | 2000 | Tunable white | >90 | N/A | DALI | IP 43 | cylindrical | N/A | - | EV-K11ST2040OP9TWDMWKombic 100 Surface Track Opal TWEV-K11ST2040OP9TWDMWDownlight with luminous flux of 2000lm. A wide range of technical parameters and appearance of the luminaire will ensure adaptation to various applications. a faceted range of polycarbonate reflector options guarantee optimal construction of the optical system and high efficiency. I protection class guarantees a high level of safety. Available with CRI 90. Luminaire type: track and spot
Mounting type: surface mounting
Mounting location: ceiling
Luminous flux (lm): 2000
Maximum luminous efficacy (lm/W): N/A
Correlated color temperature (K): Tunable white
Color rendering index (CRI): >90
Median useful life: Lifetime: 70.000 L80 B10
Standard Deviation of Color Matching (SDCM): N/A
Luminous intensity distribution direction: N/A
Beam angle: N/A
Luminous intensity distribution: N/A
Colour: white 02
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Angle 65° luminance: N/A
Voltage (V AC): 230
Power (W): 20,7
Wired lighting control: DALI
Wireless lighting control: N/A
IP Code: IP 43
IK Code: N/A
IEC protection class: I
Diffuser material: N/A
Reflector material: polycarbonate
Reflector Finish: metalized metalic
Housing material: aluminium
Luminaire shape: cylindrical
Permissible ambient temperature range: from 0u00c2u00b0C to 25u00c2u00b0C
Width (mm): N/A
Length (mm): N/A
Height (mm): 220
Weight (kg): N/A
Diameter (mm): 100
Adjustable: yes
Optics: opal
Installation: sus. track
| |
| EV-K11ST2040OP9TWDMB | 2000 | Tunable white | >90 | N/A | DALI | IP 43 | cylindrical | N/A | - | EV-K11ST2040OP9TWDMBKombic 100 Surface Track Opal TWEV-K11ST2040OP9TWDMBDownlight with luminous flux of 2000lm. A wide range of technical parameters and appearance of the luminaire will ensure adaptation to various applications. a faceted range of polycarbonate reflector options guarantee optimal construction of the optical system and high efficiency. I protection class guarantees a high level of safety. Available with CRI 90. Luminaire type: track and spot
Mounting type: surface mounting
Mounting location: ceiling
Luminous flux (lm): 2000
Maximum luminous efficacy (lm/W): N/A
Correlated color temperature (K): Tunable white
Color rendering index (CRI): >90
Median useful life: Lifetime: 70.000 L80 B10
Standard Deviation of Color Matching (SDCM): N/A
Luminous intensity distribution direction: N/A
Beam angle: N/A
Luminous intensity distribution: N/A
Colour: black 02
Luminous intensity distribution geometry: N/A
Luminous intensity distribution: N/A
Unified glare rating (UGR): N/A
Angle 65° luminance: N/A
Voltage (V AC): 230
Power (W): 20,7
Wired lighting control: DALI
Wireless lighting control: N/A
IP Code: IP 43
IK Code: N/A
IEC protection class: I
Diffuser material: N/A
Reflector material: polycarbonate
Reflector Finish: metalized metalic
Housing material: aluminium
Luminaire shape: cylindrical
Permissible ambient temperature range: from 0u00c2u00b0C to 25u00c2u00b0C
Width (mm): N/A
Length (mm): N/A
Height (mm): 220
Weight (kg): N/A
Diameter (mm): 100
Adjustable: yes
Optics: opal
Installation: sus. track
| |
