| Product code | Luminous flux (lm) | Correlated color temperature (K) | Color rendering index (CRI) | Unified glare rating (UGR) | Wired lighting control | IP Code | Luminaire shape | Length (mm) | | Info | Add |
|---|
| EV-MD1120SF0120830NW | 100 | 3000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1120SF0120830NW| Photo |  |
|---|
| Product code | EV-MD1120SF0120830NW |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 100 |
|---|
| Maximum luminous efficacy (lm/W) | 62.5 |
|---|
| Correlated color temperature (K) | 3000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | White 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 1.6 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 120 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø120 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 3000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1120SF0120840NW | 100 | 4000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1120SF0120840NW| Photo | |
|---|
| Product code | EV-MD1120SF0120840NW |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 100 |
|---|
| Maximum luminous efficacy (lm/W) | 62.5 |
|---|
| Correlated color temperature (K) | 4000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | White 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 1.6 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 120 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø120 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 3000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1120SF0120830NB | 100 | 3000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1120SF0120830NB| Photo | |
|---|
| Product code | EV-MD1120SF0120830NB |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 100 |
|---|
| Maximum luminous efficacy (lm/W) | 62.5 |
|---|
| Correlated color temperature (K) | 3000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | Black 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 1.6 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 120 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø120 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 3000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1120SF0120840NB | 100 | 4000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1120SF0120840NB| Photo | |
|---|
| Product code | EV-MD1120SF0120840NB |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 100 |
|---|
| Maximum luminous efficacy (lm/W) | 62.5 |
|---|
| Correlated color temperature (K) | 4000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | Black 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 1.6 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 120 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø120 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 3000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1180SF0120830NW | 150 | 3000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1180SF0120830NW| Photo | |
|---|
| Product code | EV-MD1180SF0120830NW |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 150 |
|---|
| Maximum luminous efficacy (lm/W) | 71.4 |
|---|
| Correlated color temperature (K) | 3000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | White 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 2.1 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 180 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø180 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 4000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1180SF0120830NB | 150 | 3000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1180SF0120830NB| Photo | |
|---|
| Product code | EV-MD1180SF0120830NB |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 150 |
|---|
| Maximum luminous efficacy (lm/W) | 71.4 |
|---|
| Correlated color temperature (K) | 3000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | Black 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 2.1 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 180 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø180 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 4000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1180SF0120840NB | 150 | 4000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1180SF0120840NB| Photo | |
|---|
| Product code | EV-MD1180SF0120840NB |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 150 |
|---|
| Maximum luminous efficacy (lm/W) | 71.4 |
|---|
| Correlated color temperature (K) | 4000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | Black 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 2.1 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 180 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø180 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 4000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1180SF0120840NW | 150 | 4000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1180SF0120840NW| Photo | |
|---|
| Product code | EV-MD1180SF0120840NW |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 150 |
|---|
| Maximum luminous efficacy (lm/W) | 71.4 |
|---|
| Correlated color temperature (K) | 4000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | White 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 2.1 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 180 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø180 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 4000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1300SF0120830NW | 300 | 3000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1300SF0120830NW| Photo | |
|---|
| Product code | EV-MD1300SF0120830NW |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 300 |
|---|
| Maximum luminous efficacy (lm/W) | 81.1 |
|---|
| Correlated color temperature (K) | 3000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | White 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 3.7 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 300 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø300 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 3000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1300SF0120830NB | 300 | 3000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1300SF0120830NB| Photo | |
|---|
| Product code | EV-MD1300SF0120830NB |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 300 |
|---|
| Maximum luminous efficacy (lm/W) | 81.1 |
|---|
| Correlated color temperature (K) | 3000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | Black 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 3.7 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 300 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø300 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 3000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1300SF0120840NB | 300 | 4000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1300SF0120840NB| Photo | |
|---|
| Product code | EV-MD1300SF0120840NB |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 300 |
|---|
| Maximum luminous efficacy (lm/W) | 81.1 |
|---|
| Correlated color temperature (K) | 4000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | Black 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 3.7 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 300 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø300 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 3000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
| EV-MD1300SF0120840NW | 300 | 4000 | >80 | N/A | ON/OFF | IP 20 | round | N/A |
| EV-MD1300SF0120840NW| Photo | |
|---|
| Product code | EV-MD1300SF0120840NW |
|---|
| Luminaire type | round |
|---|
| Mounting type | surface mounting |
|---|
| Mounting location | wall, ceiling |
|---|
| Luminous flux (lm) | 300 |
|---|
| Maximum luminous efficacy (lm/W) | 81.1 |
|---|
| Correlated color temperature (K) | 4000 |
|---|
| Color rendering index (CRI) | >80 |
|---|
| Median useful life | 50.000 L70 B50. |
|---|
| Standard Deviation of Color Matching (SDCM) | SDCM <3 |
|---|
| Luminous intensity distribution direction | indirect |
|---|
| Beam angle | N/A |
|---|
| Luminous intensity distribution | N/A |
|---|
| Colour | White 05 |
|---|
| Luminous intensity distribution geometry | symmetrical |
|---|
| Luminous intensity distribution | N/A |
|---|
| Unified glare rating (UGR) | N/A |
|---|
| Angle 65° luminance | N/A |
|---|
| Voltage (V AC) | 230 |
|---|
| Power (W) | 3.7 |
|---|
| Wired lighting control | ON/OFF |
|---|
| Wireless lighting control | N/A |
|---|
| IP Code | IP 20 |
|---|
| IK Code | N/A |
|---|
| IEC protection class | I |
|---|
| Diffuser material | N/A |
|---|
| Diffuser type | N/A |
|---|
| Reflector material | N/A |
|---|
| Housing material | N/A |
|---|
| Luminaire shape | round |
|---|
| Permissible ambient temperature range | from 0°C to 25°C |
|---|
| Circuit load capacity (B10) | N/A |
|---|
| Circuit load capacity (B16) | N/A |
|---|
| Width (mm) | N/A |
|---|
| Length (mm) | N/A |
|---|
| Height (mm) | N/A |
|---|
| Weight (kg) | N/A |
|---|
| Diameter (mm) | 300 |
|---|
| Ceilling opening dimensions (mm) | N/A |
|---|
| Generic description | Indirect radiation wall mounted fixture model MUN DARK Ø300 LAMP brand. Made of aluminum with opal polycarbonate diffuser. Model for LED with 3000K color temperature, CRI 80 and control gear included. IP20 protection rating. Insulation class I. Lifetime: 50.000 L70 B50. Available finishes: White and textured graphite. |
|---|
| IES | Download |
|---|
| Optics | N/A |
|---|
| |
