Product code | Luminous flux (lm) | Correlated color temperature (K) | Color rendering index (CRI) | Unified glare rating (UGR) | Wired lighting control | IP Code | Luminaire shape | Length (mm) | | Info | Add |
---|
EV-FXX142121 | 4000 | 4000 | >80 | N/A | DALI | IP 20 | linear | 1142 |
| EV-FXX142121Photo | ![](/wp-content/themes/lighttheme/product-files/fx45_1142_dk_silent_black_image.png) |
---|
Product code | EV-FXX142121 |
---|
Luminaire type | N/A |
---|
Mounting type | suspended |
---|
Mounting location | ceiling |
---|
Luminous flux (lm) | 4000 |
---|
Maximum luminous efficacy (lm/W) | 133 |
---|
Correlated color temperature (K) | 4000 |
---|
Color rendering index (CRI) | >80 |
---|
Median useful life | Average durability of LED L80B50 Tₐ25 (h)
100,000
Power supply life for Tₐ=25, failure rate 10% (h)
100,000 |
---|
Standard Deviation of Color Matching (SDCM) | SDCM <3 |
---|
Luminous intensity distribution direction | N/A |
---|
Luminous intensity distribution | N/A |
---|
Colour | black |
---|
Luminous intensity distribution geometry | symmetrical |
---|
Luminous intensity distribution | N/A |
---|
Unified glare rating (UGR) | N/A |
---|
Voltage (V AC) | 220-240 |
---|
Power (W) | 30 |
---|
Wired lighting control | DALI |
---|
IP Code | IP 20 |
---|
IK Code | N/A |
---|
IEC protection class | I |
---|
Diffuser material | N/A |
---|
Diffuser type | DK |
---|
Reflector material | N/A |
---|
Housing material | Aluminium |
---|
Luminaire shape | linear |
---|
Permissible ambient temperature range | from 0°C to 25°C |
---|
Width (mm) | 62 |
---|
Length (mm) | 1142 |
---|
Height (mm) | N/A |
---|
Weight (kg) | N/A |
---|
Diameter (mm) | 4000 |
---|
Generic description | FX45 SILENCE combines excellent optical performance with acoustic functionality, without any compromises in terms of design. This product is covered with pressed polyester fiber called PET on both sides and filled with special absorbing materials that reduce noise, improving the comfort of everyone who uses the space. When implementing the Human Centric Lighting (HCL) concept, we place the main emphasis on people and their needs. PET is a non-toxic, non-flammable and 75% recycled acoustic material, also available in a variety of colors to match any interior design. DARKPOINT (DK) optics guarantee excellent glare control and exceptional aesthetics. |
---|
LDT | Download |
---|
IES | Download |
---|
Installation instructions | Download |
---|
| |
EV-FXX142122 | 6000 | 4000 | >80 | N/A | DALI | IP 20 | linear | 1701 |
| EV-FXX142122Photo | ![](/wp-content/themes/lighttheme/product-files/fx45_1142_dk_silent_black_image.png) |
---|
Product code | EV-FXX142122 |
---|
Luminaire type | N/A |
---|
Mounting type | suspended |
---|
Mounting location | ceiling |
---|
Luminous flux (lm) | 6000 |
---|
Maximum luminous efficacy (lm/W) | 139 |
---|
Correlated color temperature (K) | 4000 |
---|
Color rendering index (CRI) | >80 |
---|
Median useful life | Average durability of LED L80B50 Tₐ25 (h)
100,000
Power supply life for Tₐ=25, failure rate 10% (h)
100,000
Luminous flux drop (LLMF) 50,000 h Tₐ25
0.90 |
---|
Standard Deviation of Color Matching (SDCM) | SDCM <3 |
---|
Luminous intensity distribution direction | N/A |
---|
Luminous intensity distribution | N/A |
---|
Colour | black |
---|
Luminous intensity distribution geometry | symmetrical |
---|
Luminous intensity distribution | N/A |
---|
Unified glare rating (UGR) | N/A |
---|
Voltage (V AC) | 220-240 |
---|
Power (W) | 43 |
---|
Wired lighting control | DALI |
---|
IP Code | IP 20 |
---|
IK Code | N/A |
---|
IEC protection class | I |
---|
Diffuser material | N/A |
---|
Diffuser type | DK |
---|
Reflector material | N/A |
---|
Housing material | Aluminium |
---|
Luminaire shape | linear |
---|
Permissible ambient temperature range | from 0°C to 25°C |
---|
Width (mm) | 62 |
---|
Length (mm) | 1701 |
---|
Height (mm) | 500 |
---|
Weight (kg) | N/A |
---|
Diameter (mm) | 4000 |
---|
Generic description | FX45 SILENCE combines excellent optical performance with acoustic functionality, without any compromises in terms of design. This product is covered with pressed polyester fiber called PET on both sides and filled with special absorbing materials that reduce noise, improving the comfort of everyone who uses the space. When implementing the Human Centric Lighting (HCL) concept, we place the main emphasis on people and their needs. PET is a non-toxic, non-flammable and 75% recycled acoustic material, also available in a variety of colors to match any interior design. DARKPOINT (DK) optics guarantee excellent glare control and exceptional aesthetics. |
---|
LDT | Download |
---|
IES | Download |
---|
Installation instructions | Download |
---|
| |
